Native, custom and async dropdowns, and iframes, framesets and nested frames with frameLocator()

• The three kinds of dropdown: native select, custom, and advanced
• Native select: selectOption() by label, value or index
• Custom dropdowns: open the trigger, then pick by role or by text
• getByText's partial match, exact: true, and the strict mode error
• Advanced dropdowns: searchable, multi-select chips, creatable, and async
• Keeping a menu open while you inspect it in DevTools
• Frames versus iframes: the legacy frameset and the modern iframe
• frameLocator(): filling a form inside one iframe
• A frameset page: listing its frames, then working in one
• Nested iframes three levels deep, and the strict mode failure
• Keyboard and mouse actions, in brief
• Two tasks: the QA Profile form and the selector battle

The class sorted dropdowns into three groups, because each needs a different approach:

• Native. A real <select> element with <option> children. The browser owns it, and Playwright sets it in one call.
• Custom. Divs styled to look like a dropdown. Clicking a trigger opens a menu, and each item is a div with role="option".
• Advanced. Custom menus with extra behaviour: searchable, multi-select with chips, creatable, grouped, and async, where the options are fetched after you type.

selectOption() only works on the first kind. Everything else follows the class's two-step formula: open the dropdown, then select by role or text.

The first spec uses a plain <select id="dropdown"> with two options:

import { test, expect, Locator } from '@playwright/test';

test('Verify DropDowns', async ({ page }) => {
   await page.goto("https://the-internet.herokuapp.com/dropdown");

   await page.locator("#dropdown").click();
   await page.selectOption("#dropdown", "Option 2");

   await page.pause();
});

There is no Select class to import, as there is in Selenium. selectOption() takes the option's visible label, its value attribute, or its index, and one parameter accepts all of these shapes:

const dropdown = page.locator('#dropdown');

await dropdown.selectOption('Option 2');            // a string matches the value or the label
await dropdown.selectOption({ label: 'Option 1' }); // the visible text
await dropdown.selectOption({ value: '2' });        // the value attribute
await dropdown.selectOption({ index: 1 });          // the position, counting from 0

Each call returns the values it selected: ['2'], ['1'], ['2'] and ['1']. Index 1 is Option 1, not Option 2, because index 0 is the disabled "Please select an option" placeholder.

The second spec drives two custom dropdowns on the dropdowns practice page. Neither is a <select>, so selectOption() would throw. Each takes two clicks: one to open the menu, one to pick the option.

import { test, expect, Locator } from '@playwright/test';

test('Verify Custom DropDowns', async ({ page }) => {
   await page.goto('https://app.thetestingacademy.com/playwright/tables/dropdowns');

   await page.getByTestId('lang-trigger').click();
   await page.getByRole("option", { name:"JavaScript" }).click();

   // await page.getByText("JavaScript").first().click();

   await page.getByTestId('experience-trigger').click();
   await page.getByText("Mid-level (4-6 years)", { exact: true }).click();


   await page.pause();
});

• Open it. The trigger carries data-testid="lang-trigger", which is exactly what getByTestId() reads.
• Pick by role. The menu items are plain divs, but each has role="option", so getByRole('option', { name: 'JavaScript' }) finds the right one. If the items had no role, a class selector through page.locator() would do the same job.
• Or pick by text. getByText() also works once the menu is open, with one catch.

exact: true. getByText() does a partial, case-insensitive match by default, so a short string also matches any longer text that contains it. { exact: true } demands the whole string, case included. The option is optional, which is what the question mark in its type, exact?: boolean, means.

The third spec works through the react-select style menus on the select-boxes practice page. The comments are as pushed, with their dashes shown as colons.

import { test, expect, Locator } from '@playwright/test';

test('Verify Advance Custom DropDowns', async ({ page }) => {
   await page.goto('https://app.thetestingacademy.com/playwright/tables/select-boxes');

       // ① Single: searchable

   await page.locator('#rs-single').click();
   await page.getByText("Cypress").click()

     // ②  Multi: chips with remove
   await page.locator("#rs-multi").click();
   await page.getByText("Pytest", { exact: true }).click();
   await page.getByText("JUnit", { exact: true }).click();
   await page.keyboard.press("Escape");


    // ③ Creatable multi: type and Enter
    await page.locator("#rs-creatable").click();
    await page.getByText("api-testing", { exact: true }).click();
    await page.getByText("security", { exact: true }).click();
    await page.keyboard.press("Escape");


    // ⑤ Async: fetched on type


    await page.locator("#rs-async").click();
    await page.getByTestId('rs-async-input').fill('de');
    await expect(page.getByTestId('rs-async-menu')).toContainText('Delhi');
    await page.getByRole('option',{ name: "Delhi", exact :true},).click();

   await page.pause();
});

The async menu is the one the class flagged as an interview favourite. Step by step:

Typing de returns two cities, because both names contain those letters. That is why the pick names its option exactly.

Questions from the class:

• Do I need a loop to find the option? No. In Selenium you would collect the options and loop until the text matches. getByRole('option', { name }) goes straight to it. Looping over a list of values you want to pick, to avoid repeating the same line, is fine.
• What if an option's text has extra spaces? The class suggested falling back to page.locator() with normalize-space(). That function belongs to XPath, not CSS, and you rarely need it: getByText() and the name option of getByRole() already trim and collapse whitespace, even with exact: true.
• How do I remove a chip? Each chip's close button has the accessible name "Remove api-testing", so page.getByRole('button', { name: 'Remove api-testing' }) or page.getByLabel('Remove api-testing') finds it, and a click removes the chip.
• Can page.close() close the menu? No. page.close() closes the whole page, the browser tab the test is running in. Use Escape or a click outside.
• Toast messages that vanish after two or three seconds are handled the same way, and come in a later class.

An iframe embeds a whole separate HTML document inside the page. It is the modern way to do it, and nearly every site you meet uses iframes: payment forms, embedded editors and third-party widgets are the usual cases. A frameset is the older way. Before HTML5, a page could be split into frames, such as a side menu, a main area and a footer, each holding its own document. HTML5 dropped <frameset>, but browsers still render it and Playwright handles both.

Either way the elements live in a different document, so page.locator() cannot see them. There is no switching step, as there is with driver.switchTo().frame() in Selenium: you get a frame locator, then use it wherever you would have used page.

The frames practice page embeds a vehicle registration form in an iframe with the id frame-one. Every line after the first uses the frame locator where it would otherwise use page:

import { test, expect, Locator, FrameLocator } from '@playwright/test';

test('Verify Advance Custom DropDowns', async ({ page }) => {
  await page.goto('https://app.thetestingacademy.com/playwright/frames/');
  let vechileFrame: FrameLocator = await page.frameLocator("#frame-one");

  await vechileFrame.locator('#RESULT_TextField-1').fill('Hyundai i10');
  await vechileFrame.locator('#RESULT_TextField-2').fill('Pramod Dutta');
  await vechileFrame.locator('#RESULT_TextField-3').fill('2012');
  await vechileFrame.locator('#RESULT_RadioButton-1').selectOption('Hatchback');

  await vechileFrame.locator('#RESULT_TextField-4').fill('2015');

  await vechileFrame.locator('#RESULT_TextArea-1').fill('Amazing car with amazing family car in a budget');

  await vechileFrame.getByText('Submit registration', { exact: true }).click();

  let output = await vechileFrame.locator("#vehicle-output").innerText();
  console.log(output);
  await page.pause();
});

After the submit, the form's output panel shows what was entered, and the spec prints it:

{
  "vehicleName": "Hyundai i10",
  "ownerName": "Pramod Dutta",
  "regNumber": "2012",
  "vehicleType": "Hatchback",
  "year": "2015",
  "notes": "Amazing car with amazing family car in a budget"
}

Note the selectOption() call: the vehicle type field is a native <select>, so the first half of the class applies inside the frame too.

When the iframe has no id. The class's order of preference is id, then name, then src, then title, with the index as the last resort. The vehicle iframe carries all four attributes, so each of these reaches the same frame:

page.frameLocator('#frame-one');                                            // id
page.frameLocator('iframe[name="vehicle-form"]');                           // name
page.frameLocator('iframe[src="./registration-form.html"]');                // src
page.frameLocator('iframe[title="Vehicle registration form (frame one)"]'); // title
page.locator('iframe').nth(0).contentFrame();                               // index, from 0

The last line is the current way to pick a frame by position. page.frameLocator('iframe').nth(0) still runs, but it is deprecated in favour of locator().nth() followed by contentFrame().

The multi-frames practice page is a frameset with three frames. The fourth spec reads the main frame's heading, lists every frame, then clicks a link in the side frame:

import { test, expect, Locator, FrameLocator } from '@playwright/test';

test('Verify Advance Custom DropDowns', async ({ page }) => {
  await page.goto('https://app.thetestingacademy.com/playwright/frames/multi-frames');

  let mainFrame: FrameLocator = await page.frameLocator('[name="main"]');
  const headerText = await mainFrame.locator('h2').innerText();
  console.log(headerText);


    const allFrames: Locator[] = await page.locator('//frame').all();
    console.log('total number of frames: ' + allFrames.length);

     for (const frame of allFrames) {
        console.log(await frame.getAttribute('name'), ': ', await frame.getAttribute('src'));

    }


    let sideFrame: FrameLocator = await page.frameLocator('[name="side"]');
    await sideFrame.getByTestId('side-link-registration').click();



  await page.pause();
});

It prints the heading (whose dash is shown here as a hyphen), then the three frames:

Main frame - practice playground
total number of frames: 3
side :  ./side-frame.html
main :  ./main-frame.html
footer :  ./footer-frame.html

• Frames on a frameset have names, so [name="main"] reaches the main frame, and h2 inside it is its heading.
• When you do not know the names, page.locator('//frame').all() returns one locator per <frame> element, and the for...of loop prints each one's name and src.
• Then any frame is one call away. sideFrame.getByTestId('side-link-registration') clicks the link in the side menu.

That link loads the vehicle registration form into the main frame: a link in one frame changing the document in another is how frameset menus work. In class this was described as an iframe inside the side frame, to be reached by chaining once more. Running it shows no extra iframe, so the form is one frame locator away, through the main frame:

const main = page.frameLocator('[name="main"]');
await main.locator('#RESULT_TextField-1').fill('Hyundai i10');

The last example came from an interview a student sat: three iframes, each inside the last, each holding one text field. The page is an outside practice site, so it is not linked here. The full spec, URL included, is in the batch repo as 248_Nested_Iframe_TestCase.spec.ts. From after the page.goto() line:

  let frame1: FrameLocator = page.frameLocator('#pact1');
  let frame2: FrameLocator = frame1.frameLocator('#pact2');
  let frame3: FrameLocator = frame2.frameLocator('#pact3');

  await frame1.locator('#inp_val').fill('Aishwarya Rai');
  await frame2.locator('#jex').fill('Wife');
  await frame3.locator('#glaf').fill('Playwright');

  const headerText = await frame1.locator('h3').innerText();
  console.log(headerText);
  await page.waitForTimeout(5000);
  page.keyboard

The chain is the whole idea: find frame one from the page, frame two from frame one, and frame three from frame two. #jex and #glaf are simply the ids that page's developers chose.

It fails as pushed. Run it, and the first fill() throws:

Error: locator.fill: Error: strict mode violation: locator('#pact1') resolved to 2 elements

The page has two iframes with the id pact1. Ids are supposed to be unique, but nothing enforces it, and a frame locator is as strict as any other locator. The class named the fix: pick one with first(). For frames, current Playwright writes that as locator().first() followed by contentFrame():

const frame1: FrameLocator = page.locator('#pact1').first().contentFrame();
const frame2: FrameLocator = frame1.frameLocator('#pact2');
const frame3: FrameLocator = frame2.frameLocator('#pact3');

With that change all three fields fill, and the spec prints the heading inside frame one:

Dare For You

page.frameLocator('#pact1').first() also runs, but it is deprecated. Two leftovers in the pushed file are worth knowing about. page.keyboard on a line of its own does nothing: it names the keyboard object without calling anything, and was the start of the next topic. And waitForTimeout(5000) is a fixed five-second pause for watching the result, not something to keep in a real test.

The frame panels, 1 to 4, cover this class. The popup and new-tab panels, 5 to 7, are ahead of it: pop-ups come in an upcoming class. The sheet also uses page.frame(), which returns a Frame object, or null when nothing matches, which is why its examples call frame?.locator() with optional chaining. The class used frameLocator() throughout, and the sheet marks it as the recommended way.

The class closed with a quick tour of page.keyboard, an interface that hangs off the page (hover over it in VS Code to see its methods). Worked examples come in later classes.

Mouse-style actions live on the locator: hover(), dblclick(), click(), dragTo() and scrollIntoViewIfNeeded(), with page.mouse.wheel() for scrolling and page.mouse.down() for pressing a button.

• Code: all six specs are in the batch repo, in tests/08_Web_Select_Frames_Iframe and tests/09_Frame_Iframe.
• Coming tomorrow: a cricket scorecard problem for following-sibling and preceding-sibling XPath. Given a batter's name, find their runs, balls, fours and sixes, then find the top scorer across two innings. It has come up in interviews.
• The OrangeHRM task from the web tables class is still open, and a hint is coming.
• Still to come: pop-ups, toast messages, and a class of their own for assertions.
